Hydraulic Piling Hammer 2400
A high-output hydraulic piling hammer designed for driving larger steel piles where higher impact energy and stable operating weight are required.
Hydraulic Piling Hammer 2400 – High-Energy Piling Hammer
This Hydraulic Piling Hammer 2400 features a 1900 kg ram with an impact velocity of 4.98 m/s, delivering up to 24 kNm of maximum transferred energy. With blow rates of 80–120 bpm, the hammer provides controlled energy transfer for deeper or heavier piling tasks. The hammer is supplied in multiple configurations, ranging from 3598 kg leader-mounted to 7600 kg when free-hanging with a 914 mm guide sleeve. Its 520 mm minimum width and 4430 mm leader-mounted length make it adaptable to crane, leader or piling gate deployment for coastal, port and marine civil engineering projects.
Areas we service
Our vessels and equipment are available for hire across the UK, supporting marine projects on the Thames and London waterways, the South Coast and Medway, the Bristol Channel and ports throughout Devon and Cornwall. We regularly work across rivers, estuaries, harbours and coastal construction sites, with mobilisation to European locations also available for suitable projects.
