piling hammer
PILING HAMMER
|
Ram Weight |
385kg |
|
Energy per blow (max) |
650Kg.m
|
|
Blow per min (max) |
225
|
|
Air needed at 7 bar |
17m3
|
|
Rope Speed Aux. drum hoist/lowering |
17m3
|
|
Air hose bore |
51mm
|
|
Weight of basic hammer with legs |
3006kg
|
|
Height above pile |
1650mm
|
|
Overall height with legs |
2420mm
|
|
Depth of anvil face |
356mm
|
|
Narrow anvil width |
457mm
|
|
Wide anvil width |
711mm |
Hydraulic Piling Hammer 1200
|
Ram Weight |
1040KG |
|
Impact Velocity |
4.76m
|
|
Maximum Energy Transferred to Pile |
12KNm
|
|
Minimum Energy transferred to Pile |
6.2KNm
|
|
Blow Rate |
80-1202 bpm
|
|
Length-Lead Mounted |
3800mm
|
|
Minimum Width of Body |
406mm
|
|
Weight Lead Mounted |
3000kg |
|
Weighted with Sheet Pile Leg Guides + Spreader Plate |
3000kg
|
Hydraulic Piling Hammer 2400
|
Ram Weight |
1900kg |
|
Impact Velocity |
4.98m/s
|
|
Maximum Energy Transferred to Pile |
24,00 KNm
|
|
Minimum Energy transferred to Pile |
10KNm
|
|
Blow Rate |
80-120 bpm
|
|
Length-Lead Mounted |
4430mm |
|
Minimum Width of Body |
520mm
|
|
Weight Lead Mounted |
6000kg
|
|
Weighted with Sheet Pile Leg Guides + Spreader Plate |
7000kg
|
|
Weight – Free Hanging with 0914 Guide Sleeve |
7600kg
|
